Voice-Video-Data Recording & Replay System

3R System

The 3R System is a modular Voice-Video-Data Recording and Replay solution designed to meet diverse performance, operational, and safety requirements.

Built on a Service-Oriented Architecture, it enables flexible deployment across single or multiple networked devices. Its scalable design allows for customized configurations tailored to the specific needs of each customer.

Download 3R brochure
ABOUT ERIS-A

Description

The 3R System provides a high level of modularity, which allows us to deliver to our customers a variety of 3R configurations according to their requirements for performance, and operational and safety parameters of the proposed solution.

The 3R SW is built on Service-Oriented Architecture (SOA) integrating distributed, separately maintained, and deployed software components, thus allowing 3R processes and applications to run on one or multiple devices connected to one network as required.

Benefits

  • Shorter time of investigation files sharing across the team

  • Based on COTS HW components+

  • Easy export of given sequence

  • Independent Data Display for surveillance data

  • Selectable channels for on-line monitoring

    • ABOUT ERIS-A

    System architecture

    3R modules can be operated on one computer, one or more servers, and one or multiple workstations, and configured in compliance with required performance, operational, and safety specifications.

  • 3R Recorder – Audio/Video/VoIP/Data – Recording Module

  • CSS and CS – Central Storage and Central Server

  • CMS – Monitoring & Diagnostics and System Configuration Module

  • 3R Player – Replay and Investigation Module

  • 3R RDD – Radar Data Replay and Investigation Module

  • New module DART – Data Analysis and Replay Tool provides an interactive and advanced multi-level surveillance data analysis, from packets to decoded ASTERIX message inspector, to trajectories.

    • Structure

    System features

    365/24/7 operation

    Retention period of at least 30 days

    Multi-source/multi-channel design

    Secure communication within 3R environment

    ATC/ATM-specific Monitoring and Diagnostics (status, notification, alert)

    Incident Management tools

    User Management

    Centralized System Configuration

    Centralized Monitoring and Log System

    3R system modules can run as:

  • 3R Recorder – Audio/Video/VoIP/Data – Recording Module

  • CSS and CS – Central Storage and Central Server

  • CMS – Monitoring & Diagnostics and System Configuration Module

    • 3R modules can be deployed as:

  • A stand-alone computer

  • One or more servers, and one or multiple workstations

  • Configured to required performance, operational, and safety specifications
